Fanuc Main Panel A1 MOP for 16i/ 18i/ 21i A02B-0236-C240

A02B-0236-C240 is an LCD display unit used on the CNC operator panel of systems manufactured by FANUC.

📌 Basic Information

• Part Number: A02B-0236-C240

• Type: LCD Display Unit

• Category: CNC Operator Interface (HMI)

• Used In: FANUC CNC controllers (commonly Series 16i / 18i / 21i)

🖥️ Main Functions

The A02B-0236-C240 unit serves as the main display screen on the CNC operator panel.

Key functions include:

• Displaying NC programs and editing screens

• Showing machine status and alarm messages

• Displaying axis position, tool data, and offsets

• Showing parameters and diagnostic information

• Supporting operator interaction with the CNC control

🧩 Installation Location

This display unit is typically installed:

• On the front operator panel of the CNC machine

• Connected to the CNC control unit and operator keyboard

🔎 Related Models

Other display units in the A02B-0236 series include:

• A02B-0236-C140

• A02B-0236-C141

• A02B-0236-C150

• A02B-0236-C230

• A02B-0236-C240

These models represent different hardware versions or display configurations used in FANUC CNC operator panels.

✅ Simple explanation:
A02B-0236-C240 = FANUC CNC operator panel LCD display used to show CNC programs, machine status, alarms, and system information. 🔧
