Description
A02B-0281-C121#MBR is a CNC operator panel with integrated LCD display used in CNC machines equipped with controllers from FANUC.
📌 Basic Information
-
Part Number: A02B-0281-C121#MBR
-
Type: CNC Operator Panel / LCD Display Unit (HMI)
-
Controller Series: FANUC Series 0i-D
-
Category: Human–Machine Interface module
⚙️ Main Functions
The A02B-0281-C121 unit provides the operator interface for the CNC machine. Its functions include:
-
Displaying CNC operation screens and machine status
-
Allowing NC program input and editing
-
Showing alarms, diagnostics, and system information
-
Enabling manual machine control (MDI, jog, reference return)
-
Communicating with the main CNC control unit
🖥️ Typical Components
This module generally includes:
-
Integrated LCD screen
-
Operator keypad / keyboard
-
Soft keys and function keys
-
Communication interface to the CNC controller
🔎 Meaning of “#MBR”
In FANUC part numbers:
-
#MBR represents a specific configuration or option package.
-
It may define differences such as:
-
Keyboard layout
-
Language / regional version
-
Display configuration
-
Machine builder customization
-
🧩 Related Models
Within the A02B-0281 operator panel family, common variants include:
-
C120
-
C121
-
C125
These are different versions of the FANUC 0i-D operator interface, typically differing in display type, hardware revision, or keyboard layout.
✅ Simple explanation:
A02B-0281-C121#MBR = FANUC 0i-D CNC operator panel with LCD display used to operate the machine, edit programs, and monitor system status. 🔧
