Description
A02B-0281-C121#MBS is a CNC operator panel with integrated LCD display used with CNC systems from FANUC.
📌 Basic Information
-
Part Number: A02B-0281-C121#MBS
-
Type: CNC Operator Panel / LCD Display Unit (HMI)
-
Controller Series: FANUC Series 0i-D
-
Category: Human–Machine Interface (HMI)
⚙️ Main Functions
The A02B-0281-C121 panel acts as the primary interface between the machine operator and the CNC control.
Main functions include:
-
Displaying CNC operation screens
-
Showing machine status, alarms, and diagnostics
-
NC program input and editing
-
Allowing manual operations such as jog, MDI, and reference return
-
Communicating with the CNC main control unit
🖥️ Typical Components
This module typically includes:
-
LCD display
-
Operator keypad
-
Soft keys and function keys
-
Interface connectors for connection to the CNC controller
🔎 Meaning of “#MBS”
In FANUC option codes:
-
#MBS indicates a specific hardware or configuration variant of the operator panel.
-
It may define:
-
Keyboard layout
-
Display configuration
-
Machine builder customization
-
Regional or language settings
-
🧩 Related Models in the Same Series
Other panels in the A02B-0281 operator panel family include:
-
C120
-
C121
-
C125
-
C126
These are different versions of the FANUC 0i-D operator interface, with variations in display hardware or keyboard configuration.
✅ Simple explanation:
A02B-0281-C121#MBS = FANUC 0i-D CNC operator panel with LCD display used for machine operation, program editing, and system monitoring. 🔧
