Description
A02B-0281-C125#MBR is a CNC operator panel with LCD display used in machines equipped with controllers from FANUC.
📌 Basic Information
-
Part Number: A02B-0281-C125#MBR
-
Type: CNC Operator Panel / LCD Display Unit (HMI)
-
Controller Series: FANUC Series 0i-D
-
Category: Human–Machine Interface module
⚙️ Main Functions
The A02B-0281-C125 unit provides the operator interface for the CNC system and allows the operator to control and monitor the machine.
Main functions include:
-
Displaying CNC operation screens
-
Allowing NC program input and editing
-
Showing machine status, alarms, and diagnostics
-
Enabling manual machine operations (MDI, jog, reference return)
-
Communicating with the CNC main control unit
🖥️ Typical Components
This module normally includes:
-
Integrated LCD display
-
Operator keypad
-
Soft keys and function keys
-
Interface connection to the CNC controller
🔎 Meaning of “#MBR”
In FANUC part numbers:
-
#MBR indicates a specific configuration version of the panel.
-
It may represent differences such as:
-
Keyboard layout
-
Language or regional configuration
-
Display specifications
-
Machine builder customization
-
🧩 Related Models
Within the A02B-0281 operator panel family, common models include:
-
C120
-
C121
-
C125
These are different versions of FANUC 0i-D operator panels, typically differing in hardware revision, screen type, or keyboard layout.
✅ Simple explanation:
A02B-0281-C125#MBR = FANUC 0i-D CNC operator panel with LCD display used for machine operation, program editing, and monitoring the CNC system. 🔧
