Description
A02B-0281-C126#MBR is a CNC operator panel with integrated LCD display (HMI) used in machines equipped with controllers from FANUC.
📌 Basic Information
-
Part Number: A02B-0281-C126#MBR
-
Type: CNC Operator Panel / Display Unit
-
Controller Series: FANUC Series 0i-D
-
Category: Human–Machine Interface (HMI)
⚙️ Main Functions
The A02B-0281-C126 panel provides the main interface between the operator and the CNC machine. It is used for:
-
Displaying CNC operating screens and machine status
-
NC program input and editing
-
Showing alarms, diagnostics, and system messages
-
Performing manual machine operations (MDI, jog, reference return)
-
Communicating with the CNC main control unit
🖥️ Typical Components
This module usually contains:
-
Integrated LCD display
-
Operator keyboard / keypad
-
Soft keys and function keys
-
Communication interface to the CNC controller
🔎 Meaning of “#MBR”
In FANUC part numbers:
-
#MBR indicates a specific configuration or option package of the panel.
-
It may specify:
-
Keyboard layout
-
Display version
-
Regional / language configuration
-
Machine builder customization
-
🧩 Related Models in the Same Series
Other operator panels in the A02B-0281 display family include:
-
C120
-
C121
-
C125
-
C126
These are different hardware or configuration versions of the FANUC 0i-D operator interface.
✅ Simple explanation:
A02B-0281-C126#MBR = FANUC 0i-D CNC operator panel with LCD display used for operating the machine, editing programs, and monitoring CNC status. 🔧
