Fanuc Main Panel A MOP for 16i/ 18i/ 21i A02B-0236-C230

A02B-0236-C230 is an LCD display unit for the CNC operator panel used in control systems manufactured by FANUC.

📌 Basic Information

• Part Number: A02B-0236-C230

• Type: LCD Display Unit

• Category: CNC Operator Interface (HMI)

• Used In: FANUC CNC controllers (commonly Series 16i / 18i / 21i)

🖥️ Main Functions

The A02B-0236-C230 unit serves as the display screen on the CNC operator panel.

Main functions include:

• Displaying NC program screens

• Showing machine status and alarms

• Displaying axis positions and tool data

• Showing parameters and diagnostic information

• Supporting program editing and system monitoring

🧩 Installation Location

This display unit is typically installed:

• On the front operator panel of the CNC machine

• Connected to the CNC control unit and keyboard panel

🔎 Related Display Models

Other display units in the A02B-0236 series include:

• A02B-0236-C140

• A02B-0236-C141

• A02B-0236-C150

• A02B-0236-C230

These are different display versions or configurations used in FANUC operator panels.

✅ Simple explanation:
A02B-0236-C230 = FANUC CNC operator panel LCD display used to show programs, machine status, alarms, and system information. 🔧
