Description
đź“Ś Description
FANUC A08B‑0082‑B055 is a complete operator display panel from the PANEL i series used in FANUC CNC control systems. It belongs to the A08B‑0082 product family of human‑machine interface (HMI) panels and is configured with a large 15 inch LCD screen without soft keys and without touchscreen input — making it a simple, high‑visibility display for CNC operation.
🖥️ Key Features
-
15.0″ LCD display: Wide industrial display that provides clear visualization of CNC programs, machine status, alarms, and menus.
-
No soft keys: Does not include physical soft key buttons — so operator input happens via external panel controls or keyboard rather than dedicated soft key buttons on the unit.
-
No touchscreen input: Touch functionality is not supported — interaction must be done through other control elements on the CNC panel.
-
Complete assembly: This part is the full integrated PANEL i operator panel — not just an internal PCB or board — designed to install directly in the CNC machine’s control console and communicate with the controller.
🛠️ Typical Application
This display unit is used as the main human‑machine interface on CNC machines equipped with FANUC controls (like Series 0i, 16i, 18i, 21i). It’s ideal where a large screen is desired for improved readability and overview of programs and machine data, but touch or soft key input is not needed or is handled by other panel controls.
đź“Ś Summary
-
Part: A08B‑0082‑B055
-
Display: 15″ LCD
-
Soft Keys: No
-
Touchscreen: No
-
Type: Full PANEL i operator display panel for CNC controllers
