š FANUC A08B-0082-H050 ā Internal PC System Board (PANEL i, 10.4ā³ / 12.1ā³ / 15ā³ LCD)
FANUC A08B-0082-H050 is an internal printed circuit board (PCB) used inside FANUC PANEL i operator display units that include embedded PC-type functionality, specifically corresponding to the Pentium III (500 MHz) generation architecture within that family. These PC-based boards are part of a series of internal system/logic boards that provide the core computing power and control for PANEL i displays with advanced HMI features such as program file handling, graphical interfaces, and integrated PC functions.
š§ Key Function & Role
-
Internal PC/Main Logic Board: Acts as the central processing board for PANEL i display units, supporting richer embedded software and handling communication between the display subsystem and the CNC controller.
-
Pentium III Architecture: Classified under the FANUC PC board series designated as Pentium III 500 MHz cards, indicating it is a later-generation, higher-performance logic board compared with earlier MMX or Celeron boards (like H020/H021/H022 or H040/H041/H042).
-
Compatibility: It fits into PANEL i display assemblies that are designed to perform PC-based functions and likely works with associated boards such as internal storage (H100), memory (H00x series), LCD driver boards, and CNC interface circuitry.
š ļø Application Context
-
Used inside PANEL i HMI assemblies with embedded PC functions ā not an external component.
-
Available for stand-alone PANEL i display units that need a more robust internal controller board for modern/complex user interface requirements.
-
Typically found in setups where the display acts not just as a simple LCD but as a computing subsystem (e.g., file browsing, enhanced GUIs).
š Quick Summary
-
Part Number: A08B-0082-H050
-
Type: Internal PC system/main logic PCB
-
Role: Core processing and controller board in PC-based PANEL i displays
-
Generation: Pentium III era (higher performance) board
-
Use: Internal to PANEL i display assemblies with embedded PC functions
