Description
🧠Overview
-
Function: This module is a 3.5″ hard disk drive assembly, including the drive and its cooling fan, used to provide onboard storage for PANEL i systems with PC functions (such as logging, program storage, or system/OS storage).
-
Application: Commonly found in PANEL i display units that include PC features — especially in systems that run a PC‑style display subsystem (for example older PANEL i units with Windows/embedded OS and program file storage).
-
Role: A08B‑0082‑H100 and the associated A08B‑0082‑C100 represent a hard disk drive module with fan used in certain PANEL i base units with PC functions (e.g., for CNC monitors that behave like a PC).
🛠️ Usage Context
-
Used inside FANUC PANEL i CNC display modules that include a PC architecture with storage (rather than just a simple LCD controller).
-
Provides the physical storage medium and cooling for the internal software, data logging, and program file storage used by the PANEL i PC subsystem.
-
Works together with other internal PC components such as memory, CPU boards, and system boards.
đź“Ś Quick Summary
-
Part: A08B‑0082‑H100
-
Type: Hard disk drive unit (3.5″) with cooling fan
-
Use: Internal storage and cooling for FANUC PANEL i display with PC‑style functions
-
Context: Found in PANEL i base units that support embedded PC functions (e.g., Windows/OS storage) rather than basic LCD only panels.
