Description
Classification :- DI 24V/0V common input [64 points]
DO source output [48 points]
AO analog output [1 point]
Components :- Base Card RIO 2.0 terminator connector (R2-TM)
Remarks :- DI: 64-points 24V/0V common type
DO: 48- points source type (200mA/point)
AO: 1 point
Manual pulse generator input: 2ch
control unit I/F
Keyboard unit I/F
Remote I/O 2.0 I/F
RIO occupied stations (fixed): 1 to 3, 7 to 12
RIO extensible stations : 4 to 6, 13 to 64
