Description
A06B-6117-C101 is not a complete servo amplifier—it's the “unit specification” (internal model designation) of a FANUC servo amplifier module.
Basic Description
-
Manufacturer: FANUC
-
Part Number: A06B-6117-C101
-
Type: Servo amplifier unit specification (internal model code)
-
Series: αi (Alpha-i) servo amplifier system
What It Actually Means
In FANUC terminology:
-
A06B-6117-H101 → Order model (complete amplifier)
-
A06B-6117-C101 → Unit specification (internal configuration code)
So:
👉 C101 is the internal version of H101 amplifier
Related Servo Amplifier
-
Amplifier model: A06B-6117-H101
-
Servo type: αiSV-4 (small capacity servo amplifier)
Internal Components (for C101 / H101)
Typical configuration includes:
-
Wiring board: A16B-2203-0690
-
Main control PCB: A20B-2101-0040
Function
Same as the H101 amplifier, it:
-
Controls servo motor current, speed, and position
-
Processes encoder feedback
-
Communicates with CNC via FSSB (fiber optic bus)
Where You See “C101”
You usually find A06B-6117-C101:
-
In manuals / parameter sheets
-
On internal labels of the amplifier
-
In parts lists and wiring diagrams
Simple Explanation
✅ A06B-6117-C101 = internal unit specification of FANUC αiSV-4 servo amplifier (H101 model), not a separate drive.
