🔧 FANUC A06B-6117-H303 – Alpha i Servo Amplifier (3-Axis, Medium Power)

FANUC A06B-6117-H303 Servo Amplifier

---

🧠 Model Description

A06B-6117-H303 is a FANUC Alpha i (αi) servo amplifier module from the 6117 series, designed for 3-axis control with medium power capacity.

👉 Common designation: SVM3-20/20/20i

---

⚙️ Key Technical Details

• Type: AC Servo Amplifier
• Series: Alpha i (αi) – 6117 (newer generation)
• Axes: 3 axes (triple-axis module)
• Model: SVM3-20/20/20i
• Current Rating:
  • Axis 1 → 20A
  • Axis 2 → 20A
  • Axis 3 → 20A
• Communication: FSSB (fiber optic servo bus)

---

⚙️ What It Does

This amplifier:

• Drives three servo motors simultaneously
• Controls:
  • Position
  • Speed
  • Torque
• Ensures precise synchronized motion across axes
• Communicates with CNC via fiber optic (FSSB)

👉 Simple explanation:
One amplifier controls 3 medium-power CNC axes together.

---

🔍 6117 Series Advantage

Compared to older 6114 models:

• ✔ Improved efficiency and thermal design
• ✔ More compact and reliable
• ✔ Better heat dissipation
• ✔ Same multi-axis concept (3-in-1 amplifier)

---

🏭 Applications

• CNC machining centers
• CNC milling machines
• Medium-load multi-axis systems
• Industrial automation requiring synchronized motion

Typical axes:

• X, Y, Z axes in standard machining centers

---

🔑 Key Features

• ✔ 3-axis integrated amplifier (space saving)
• ✔ 20/20/20 rating → equal medium load per axis
• ✔ High precision positioning
• ✔ Built-in diagnostics and protection
• ✔ Compatible with αi servo motors

---

⚠️ Important Notes

• H303 = 3-axis module (SVM3 type)
• “20/20/20” = equal power on all three axes
• Requires:
  • Power supply module (PSM)
  • Matching αi servo motors
• Often serviced/repaired instead of replaced

---

🧠 Simple Explanation

👉 A06B-6117-H303 is a 3-axis FANUC servo amplifier designed for medium-power applications, controlling three CNC axes from a single compact unit.
