Fanuc Basic Unit for 21i A02B-0285-B500

A02B-0285-B500 is a CNC control unit (main controller module) used in CNC systems produced by FANUC.

---

📌 Basic Information

• Part Number: A02B-0285-B500

• Device Type: CNC Main Control Unit

• Controller Series: FANUC Series 31i / 32i / 35i (Model B)

• Category: High-performance CNC controller hardware

---

⚙️ Main Functions

The A02B-0285-B500 acts as the central processor of the CNC machine, responsible for:

• Executing NC machining programs (G-code / M-code)

• Performing multi-axis motion control and interpolation

• Communicating with servo amplifiers and spindle drives

• Running PMC (Programmable Machine Control) ladder logic

• Managing machine I/O signals

• Handling system alarms, diagnostics, and communication

• Controlling operator interface and display

---

🔌 Typical System Connections

This controller normally interfaces with:

• Servo amplifiers

• Spindle amplifiers

• I/O interface modules

• Operator panel and LCD display

• Memory and software modules (A87L series)

• Machine sensors and switches

---

🧩 Application

The A02B-0285 series controllers are commonly used in:

• High-end CNC machining centers

• Multi-axis milling machines

• Complex turning centers

• 5-axis machining systems

These systems require higher processing speed and advanced CNC functions compared with entry-level controllers.
