📌 FANUC A02B‑0309‑D502#M — Part Description
FANUC A02B‑0309‑D502#M is a display module used in FANUC CNC operator/control panels. It belongs to the A02B‑0309 product family of LCD/MDI (Machine Display/Interface) units found in many FANUC CNC systems.
🧠 What It Is
-
Part Number: A02B‑0309‑D502#M
-
Type: 7.2‑inch Monochrome LCD/MDI Display Unit
-
Series: FANUC A02B‑0309 (display units)
-
Suffix Meaning (
#M): Indicates the “M series horizontal mounting type” configuration for how the display panel fits into the operator panel assembly (horizontal orientation).
📺 Function & Use
This part is the visual interface screen in a FANUC CNC control panel. It displays machine status, tool data, program information, and operator menus, acting as the human‑machine interface (HMI) for the operator.
-
Display: 7.2″ monochrome (black & white) LCD
-
Purpose: Shows text, indicators, operation screens, and menus used during CNC operation
-
Used In: FANUC CNC operator panels (such as those in Series 0i‑C, 0i‑Mate, etc.) where a compact 7.2″ display is required
🛠️ Typical Applications
-
Installed in operator panel front for CNC controls
-
Replacement part for failed or damaged displays
-
Often available new, refurbished, or repaired through industrial parts suppliers with core exchange services required by many vendors
