Fanuc LCD/MDI Unit for 0i-C/ 0i Mate-C A02B-0309-D512#T

📌 FANUC A02B‑0309‑D512#T — Part Description

‑series display information can help place this part:

FANUC A02B‑0309‑D512#T is a 7.2‑inch monochrome LCD/MDI display unit used in FANUC CNC operator panels. It’s part of the A02B‑0309 product family of LCD/MDI (Machine Display/Interface) units for CNC controls.

📺 Role & Function

• Part Number: A02B‑0309‑D512#T

• Type: 7.2″ Mono LCD / MDI Display Unit

• Display Style: Monochrome (black/white) LCD with 7.2‑inch diagonal screen — common size for operator panels in FANUC Series controls.

• Series: A02B‑0309 (display/MDI modules for FANUC CNCs).

The suffix #T indicates the “T series configuration” and usually a horizontal mounting type for the display panel in the operator housing.

This unit serves as the visual interface in the CNC control — displaying menus, program information, machine status, and operator interaction data. It's not the full controller but the screen/interface module that connects to the control’s display electronics.

🧰 Typical Usage

• Installed in FANUC operator control panels (e.g., integrated into the front of the CNC machine’s human‑machine interface).

• Used with FANUC controllers like Series 0i‑C, 0i‑Mate TC, and other compatible control families that use A02B‑0309 display modules.

• Usually available as new, refurbished, or repaired via industrial spare parts suppliers with core exchange options.
