š FANUC A02B-0309-D500 ā Part Description
**** is a closely related series, but A02B-0309-D500 specifically refers to a display module used in FANUC CNC operator panels:
š§ What It Is
-
Part Number: A02B-0309-D500
-
Type: 10.4-inch Color LCD Display Unit used in FANUC CNC operator panels and control interfaces (part of the A02B-0309 family)
-
Series: A02B-0309 (LCD/MDI family)
š Key Details
-
Display Size: 10.4 inches, color LCD
-
Function: Provides the operator with visual interface for machine status, program information, and interactive control ā typically fitted into the CNC control housing.
-
Use Case: Installed in panel assemblies of FANUC CNC systems such as Series 0i-C / 0i-Mate (and possibly others that use compatible 10.4ā³ LCD units) to serve as the visual display.
-
Replacement & Repair: Commonly available as new or refurbished, and many suppliers offer repair/exchange programs.
š Context in FANUC Documentation
In official FANUC manuals, A02B-0309-D500 is listed as the 10.4ā³ LCD unit for the A02B-0309 display family ā with other variants for 7.2ā³ or 8.4ā³ screen sizes under different suffix codes.
š Summary
| Attribute | Description |
|---|---|
| Part Number | A02B-0309-D500 |
| Product Type | 10.4ā³ Color LCD Display Assembly |
| Series | FANUC A02B-0309 |
| Function | Visual display/interface for FANUC CNC control panel |
| Typical Use | Replacement screen in CNC operator units |
