📌 FANUC A20B‑0236‑C231 — Operator Panel / Main Panel B Keyboard (Symbolic)
Description:
The A20B‑0236‑C231 (often referenced interchangeably with A02B‑0236‑C231) is a MAIN PANEL B operator control panel / operator keyboard unit used in FANUC CNC control systems. It’s part of the A02B‑0236/A20B‑0236 series of operator interface hardware.
Function & Role:
-
🖥️ Operator Interface Panel: A rugged control panel with keys/buttons that acts as the primary machine operator interface on CNC equipment. It’s designed for controlling and interacting with FANUC‑controlled machines.
-
🔤 Symbolic Key Layout: This variant uses symbol‑marked keys (not full text MDI), making it suitable where symbolic labels and standard machine control keys are preferred.
-
⛔ Without MDI: This panel does not include an MDI (Manual Data Input) keypad/display — it provides the main operator controls only.
Typical Application:
-
Installed as the main operator panel B on FANUC‑based CNC controllers, especially where a symbolic key arrangement is used instead of full alphanumeric MDI.
-
Used in industrial CNC machine tools for operator command entry, mode selection, machine control operations, and navigation of machine status indicators.
Key Features:
-
🧰 Ergonomic Human‑Machine Interface: Designed for industrial use with durable keys and operator controls.
-
📦 Panel‑Mounted: Fits into the CNC control panel front face.
-
📊 Symbolic Buttons: Uses graphic/symbol‑labeled keys rather than AZ‑text keys, common on symbolic main panels.
