Description
Basic Description
-
Part / Model: A06B‑6164‑H223#H580
-
Type: AC Servo / Servo + Spindle Amplifier Module (combined unit)
-
Series / Family: “BETA” / “BiSVSP 40/40‑15” type combined servo/spindle unit.
-
Intended Use: For CNC machine tools / lathes / milling machines, to drive both servo motors and spindle from a single module.
Functional / Structural Aspects
-
Combined Unit (Servo + Spindle): This is not a pure servo drive; it is a combined BiSVSP (Bi-directional Servo + Spindle) type module (40/40‑15 in some sources) that handles both servo motor axes and the spindle from the same hardware.
-
Replacement / Exchange / Repair: Many suppliers treat it as a module you can buy refurbished or repaired, with core exchange often required.
-
Control / Compatibility: It is often paired with FANUC CNC controls such as 0i / 0i‑mate / FS / MATE‑D series.
-
Usage on Simpler/Cost‑reduced Machines: According to DNC Electronics, such combined BETA modules were used in more basic lathes to reduce complexity / cost in machine tool manufacturing.
-
