Description
Mitsubishi Electric multi-axis hybrid servo/spindle drive unit designed for CNC machine tools and industrial automation systems.
Product Description
- Manufacturer: Mitsubishi Electric
- Series: MDS-EM Series
- Model: MDS-EM-SPV3-16040
- Type: Multi-axis hybrid AC servo/spindle amplifier
- Application: CNC machining centers, lathes, milling machines, and automated production systems.
Main Function
This drive integrates:
- 3 servo axes
- 1 spindle axis
- common power/converter circuitry
into a single compact CNC drive module for Mitsubishi CNC controllers.
Model Code Meaning
MDS-EM-SPV3-16040
- MDS = Mitsubishi Drive System
- EM = Energy-efficient multi-drive series
- SPV3 = 3-axis servo + spindle hybrid drive
- 16040 = output/current class designation (160A spindle / 40A servo class)
Key Features
- 3-phase 200–230 VAC operation
- Compact multi-axis integrated architecture
- Simultaneous spindle and servo motor control
- High-speed CNC motion processing
- Built-in regenerative control
- Forced-air cooling
- Compatible with Mitsubishi M70/M700 CNC systems
- Supports Mitsubishi HG-series servo motors and SJ-series spindle motors
Technical Information
Typical specifications include:
- Input voltage: 200V class
- Servo configuration: 3-axis
- Spindle configuration: 1-axis integrated spindle
- Cooling: Forced ventilation
- Industrial use: Continuous-duty CNC operation
Compatible Motor Examples
The MDS-EM-SPV3-16040 is compatible with:
- Mitsubishi HG servo motor series
- Mitsubishi SJ spindle motor series
Typical Applications
- CNC machining centers
- Turning centers
- Milling machines
- Precision automation equipment
- Robotics and motion-control systems
Official Documentation
