Description
Mitsubishi Electric multi-axis hybrid servo/spindle drive amplifier for CNC machine tools and industrial automation systems.
Product Description
- Manufacturer: Mitsubishi Electric
- Series: MDS-EM Series
- Model: MDS-EM-SPV3-20080
- Type: Multi-axis hybrid AC servo/spindle drive unit
- Application: CNC machining centers, lathes, milling machines, and precision motion-control equipment.
Main Function
This drive unit integrates:
- 3 servo axes
- 1 spindle axis
- shared converter/power circuitry
into one compact CNC drive module for Mitsubishi CNC systems.
Model Code Meaning
MDS-EM-SPV3-20080
- MDS = Mitsubishi Drive System
- EM = Energy-efficient multi-drive series
- SPV3 = 3-axis servo + spindle hybrid type
-
20080 = output/current class designation:
- 200A spindle class
- 80A servo class
Key Features
- 3-phase 200–230 VAC operation
- Integrated spindle and servo motor control
- Compact cabinet-mount construction
- Built-in regenerative control
- High-speed CNC motion processing
- Forced-air cooling
- Designed for Mitsubishi CNC platforms such as M70/M700 series
Technical Information
Typical specifications:
- Servo configuration: 3-axis
- Spindle configuration: 1-axis integrated spindle
- Spindle nominal maximum current: 200A
- Servo current class: 80A
- Cooling: Forced ventilation
- Industrial duty: Continuous CNC machine operation
Compatible Motors
Compatible with Mitsubishi:
- HG-series servo motors
- SJ-series spindle motors
Typical Applications
- CNC machining centers
- Turning centers
- Milling machines
- Precision automation systems
- Robotics and synchronized motion-control equipment
Additional Information
The Mitsubishi MDS-EM specifications manual lists SPV3-20080 as part of the multi-axis unit lineup and specifies associated thermal and cabinet installation data.
