Siemens 6SN1118-0DM23-0AA1 – SIMODRIVE 611-D Closed-Loop Control Plug-in Unit
Part Number: 6SN1118-0DM23-0AA1
Manufacturer: Siemens
Product Family: SIMODRIVE 611-D
Module Type: Closed-Loop Control Plug-in Unit (Standard Control 2)
Product Description
The Siemens 6SN1118-0DM23-0AA1 is a SIMODRIVE 611-D closed-loop control plug-in unit for 2-axis digital servo drive systems. It provides Standard Closed-Loop Control 2 and supports direct measuring systems (SPG-S), making it suitable for high-precision feed drive and main spindle control in SINUMERIK CNC machines. It is designed for use with SIMODRIVE 611-D drive systems and can control up to two feed drive (FDD) axes or one main spindle drive (MSD).
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Siemens |
| Part Number | 6SN1118-0DM23-0AA1 |
| Product Family | SIMODRIVE 611-D |
| Module Type | Closed-Loop Control Plug-in Unit |
| Control Type | Standard Closed-Loop Control 2 |
| Number of Axes | 2 Axes |
| Supported Drives | Up to 2 Feed Drive Axes (FDD) or 1 Main Spindle Drive (MSD) |
| Measuring System | Direct Measuring System (SPG-S) |
| Encoder Support | Incremental, SIN/COS 1 Vpp, EnDat |
| Application | Digital Servo & Spindle Drives |
| Approximate Weight | 0.9 kg |
Key Features
- 2-axis closed-loop control module for SIMODRIVE 611-D
- Standard Closed-Loop Control 2 functionality
- Supports direct measuring systems (SPG-S)
- Compatible with incremental, SIN/COS 1 Vpp, and EnDat encoder interfaces
- High-precision digital servo and spindle control
- Plug-in design for easy installation and replacement
- Designed for demanding CNC machine tool applications.
Compatible Systems
- Siemens SINUMERIK 810D
- Siemens SINUMERIK 840D
- SIMODRIVE 611-D Digital Drive Systems
- Feed Drive (FDD) Applications
- Main Spindle Drive (MSD) Applications
Typical Applications
- CNC Turning Centers
- CNC Milling Machines
- Machining Centers
- Grinding Machines
- Gear Cutting Machines
- Industrial Motion Control Systems
