Description
Product Description
The Siemens 6SL3100-1DE22-0AA1 is a SINAMICS S120 Capacitor Module engineered for high-voltage DC link applications in modular SINAMICS S120 drive systems. Designed for a nominal DC link voltage of 1200 V DC, this module provides 2000 µF of capacitance to stabilize the DC bus, store regenerative energy, and reduce voltage fluctuations during dynamic machine operation. Its robust Booksize design ensures reliable integration into demanding industrial automation environments where consistent power quality and drive performance are essential.
The capacitor module enhances system efficiency by supporting voltage stabilization and energy buffering within the DC link, making it ideal for high-performance motion control systems, machine tools, robotics, material handling equipment, and automated production lines utilizing SINAMICS S120 drives.
Key Features
- Genuine Siemens SINAMICS S120 Capacitor Module
- Designed for 1200 V DC link systems
- Capacitance rating: 2000 µF
- Supports DC bus voltage stabilization
- Stores regenerative energy within the drive system
- Reduces voltage ripple and fluctuations
- Compact Booksize construction
- Seamless integration with SINAMICS S120 architecture
- Improves drive system reliability and performance
- Suitable for demanding industrial automation applications
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Siemens |
| Part Number | 6SL3100-1DE22-0AA1 |
| Product Family | SINAMICS S120 |
| Product Type | Capacitor Module |
| Nominal DC Link Voltage | 1200 V DC |
| DC Voltage Range | 950–1350 V DC |
| Capacitance | 2000 µF |
| Design Format | Booksize |
| Cooling Method | Air Cooling |
| Mounting Type | Control Cabinet |
| System Compatibility | SINAMICS S120 |
| Application | DC Link Energy Storage & Voltage Stabilization |
| Protection Class | IP20 |
| Product Lifecycle | Active Product |
| Condition | New / Original Siemens Product |
Applications
- SINAMICS S120 Drive Systems
- High-Power Motion Control Systems
- CNC Machine Tools
- Robotics and Automation
- Material Handling Equipment
- Packaging Machinery
- Printing Systems
- Conveyor Applications
- Industrial Manufacturing Lines
- Multi-Axis Servo Drive Systems
Benefits
- Stabilizes DC link voltage under dynamic load conditions
- Improves overall drive system performance
- Reduces voltage ripple and power fluctuations
- Supports energy buffering during regenerative operation
- Enhances reliability of connected drive modules
- Compact design minimizes control cabinet space requirements
- Fully compatible with Siemens SINAMICS S120 systems
