Siemens 6SL3000-0CE22-0AA0 Description
The Siemens 6SL3000-0CE22-0AA0 is a SINAMICS S120 Line Reactor designed for use with 20 kW Basic Line Modules (BLM). Operating on 3-phase 380–480 V AC, 50/60 Hz, the line reactor is installed between the mains supply and the Basic Line Module to reduce harmonic distortion, limit inrush currents, improve electromagnetic compatibility (EMC), and protect drive components from line-side disturbances. It is an essential component for ensuring reliable and efficient operation of SINAMICS S120 drive systems.
As part of the SINAMICS S120 power infrastructure, the reactor provides the line impedance required for proper Basic Line Module operation. By reducing current peaks and harmonics, it helps protect rectifier components, extends equipment life, and improves overall system stability and power quality.
The 6SL3000-0CE22-0AA0 is commonly used in CNC machine tools, packaging machinery, robotics, material handling systems, printing equipment, and industrial automation applications utilizing SINAMICS S120 Basic Line Modules.
🔧 Basic Identification
| Feature | Details |
|---|---|
| Manufacturer | Siemens |
| Product Series | SINAMICS S120 |
| Part Number | 6SL3000-0CE22-0AA0 |
| Product Type | Line Reactor |
| Application | Basic Line Module (BLM) |
| Compatible Power Rating | 20 kW |
| Input Voltage | 3 AC 380–480 V |
| Frequency | 50/60 Hz |
| Rated Current | 34 A |
| Protection Class | IP20 |
⚙️ Main Functions
- Reduces harmonic distortion on the mains supply
- Limits startup and inrush currents
- Improves electromagnetic compatibility (EMC)
- Protects Basic Line Modules from voltage transients
- Enhances power quality and system reliability
- Reduces electrical stress on power electronics
- Supports stable SINAMICS S120 drive operation
📋 Technical Specifications
| Specification | Value |
|---|---|
| Product Type | Line Reactor |
| Compatible Module | 20 kW Basic Line Module |
| Supply Voltage | 3 AC 380–480 V |
| Frequency Range | 50/60 Hz |
| Rated Current | 34 A |
| Inductance | Approx. 0.46 mH |
| Protection Rating | IP20 |
| Weight | Approx. 5.2 kg |
| Connection Type | Screw Terminals |
🧠 System Role
In a SINAMICS S120 architecture:
3-Phase AC Mains
→ 6SL3000-0CE22-0AA0 Line Reactor
→ 20 kW Basic Line Module
→ 600 V DC Link
→ Motor Modules
→ Servo Motors / Spindle Motors
The line reactor conditions incoming power and provides the required line-side impedance for reliable Basic Line Module operation while reducing harmonics and electrical disturbances.
🏭 Typical Applications
- CNC machining centers
- SINUMERIK-controlled machine tools
- Packaging machinery
- Robotics systems
- Material handling equipment
- Printing and converting machines
- Conveyor systems
- Industrial automation and motion-control systems
⭐ Key Benefits
- Improved power quality
- Reduced harmonics and electrical noise
- Enhanced protection for line modules
- Increased system reliability
- Better EMC compliance
- Extended service life of drive components
- Optimized for SINAMICS S120 Basic Line Modules
