Siemens 6SL3130-6AE15-0AB1 Description
The Siemens 6SL3130-6AE15-0AB1 is a SINAMICS S120 Active Line Module (ALM) designed to generate a regulated DC link voltage from a three-phase AC mains supply while enabling energy regeneration back to the power network. Operating on 3 AC 380–480 V, 50/60 Hz, this Active Line Module provides a highly efficient power supply solution for SINAMICS S120 drive systems and is suitable for demanding motion-control applications requiring bidirectional power flow.
Unlike conventional line modules, the Active Line Module can return braking energy generated by motors during deceleration directly to the mains supply, reducing energy consumption and minimizing the need for external braking resistors. The module also helps maintain a stable DC link voltage and supports improved power quality with low harmonic distortion.
Designed for seamless integration within the SINAMICS S120 platform, the 6SL3130-6AE15-0AB1 communicates via DRIVE-CLiQ and supports advanced diagnostics, automatic component recognition, and simplified commissioning. It is widely used in CNC machine tools, robotics, printing machinery, packaging systems, material handling equipment, and other high-performance industrial automation applications.
🔧 Basic Identification
| Feature | Details |
|---|---|
| Manufacturer | Siemens |
| Product Series | SINAMICS S120 |
| Part Number | 6SL3130-6AE15-0AB1 |
| Product Type | Active Line Module (ALM) |
| Input Voltage | 3 AC 380–480 V |
| Frequency | 50/60 Hz |
| Cooling Method | Internal Air Cooling |
| Communication Interface | DRIVE-CLiQ |
| System Family | SINAMICS S120 |
⚙️ Main Functions
- Converts AC mains power into a regulated DC link voltage
- Regenerates braking energy back to the power grid
- Maintains stable DC bus voltage
- Reduces energy consumption and heat generation
- Minimizes harmonic distortion on the mains supply
- Supports advanced diagnostics and monitoring
- Enables efficient operation of multi-axis drive systems
📋 Technical Specifications
| Specification | Value |
|---|---|
| Product Type | Active Line Module |
| Supply Voltage | 3 AC 380–480 V |
| Frequency | 50/60 Hz |
| Cooling Method | Internal Air Cooling |
| Communication | DRIVE-CLiQ |
| System Compatibility | SINAMICS S120 |
| Mounting Design | Booksize |
🧠 System Role
In a SINAMICS S120 architecture:
3-Phase AC Mains
→ 6SL3130-6AE15-0AB1 Active Line Module
→ DC Link
→ Motor Modules
→ Servo Motors / Spindle Motors
During braking:
Motor Regenerative Energy
→ Motor Modules
→ Active Line Module
→ Returned to AC Mains
This regenerative capability improves overall energy efficiency and reduces operating costs.
🏭 Typical Applications
- CNC machining centers
- SINUMERIK-controlled machine tools
- Robotics and automation systems
- Packaging machinery
- Printing and converting equipment
- Material handling systems
- High-performance servo drive installations
- Industrial production lines
⭐ Key Benefits
- Energy regeneration to the mains supply
- Reduced operating costs
- Stable DC link voltage regulation
- Improved power quality
- Lower harmonic distortion
- Advanced diagnostics and commissioning support
- Seamless integration with SINAMICS S120 systems
